Large Nozzle Design Pressure Reducing Valve Threaded NPT / BSPT Bronze Material

Brand Name : KUNKLE

Model Number : 215V

Certification : CE

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 sets/Month

Delivery Time : 7 working days after deposit

Packaging Details : One Valve Models 215V Safety Relief Valves with 3200MD+ positioner packed with one fumigation wooden box.

Name : Valve Models 215V Safety Relief Valves with 3200MD+ positioner

Brand : KUNKLE

Model : 215V

Connections : Threaded NPT or BSPT

Temperature range : -20° to 406°F (-29° to 208°C)

Sizes : 50, 65 and 80 mm

Vacuum range : 2" to 29" Hg (67.7 to 982 mbarg)

Valve Type : Safety Relief Valves

Codes : PED

Material : Bronze

Contact Now

Valve Models 215V Safety Relief Valves with 3200MD+

positioner

SPECIFICATION

Product Name Valve Models 215V Safety Relief Valves with 3200MD+ positioner
size 2”, 2½” and 3” [50, 65 and 80 mm]
Brand KUNKLE
Model 215V
Connections Threaded NPT or BSPT
Temperature range -20° to 406°F (-29° to 208°C)
Vacuum range 2" to 29" Hg (67.7 to 982 mbarg)
Valve Type Safety Relief Valves
Codes PED
Material Bronze


Product Description

Kunkle Valve Models 215V/337 Safety Relief Valves

Cast iron non-code vacuum relief and ASME Section VIII air/gas, ‘UV’, National Board certified safety valves, both PED certified for non-hazardous gas

Features:

  • Large nozzle design provides high capacity.
  • Flat bronze valve seats are lapped for optimum performance.
  • Warn ring offers easy adjustability for precise opening with minimum pre-open or simmer.
  • Pivot between disc and spring corrects misalignment and compensates for spring side thrust.
  • Model 215V has seal cap for vacuum service.
  • Model 337 has 'lift-pin' lift device for easy manual testing.
  • Bronze nozzle and disc as standard. Optional SS trim available.
  • Each valve tested and inspected for pressure setting and leakage.

Applications:


• Bulk hauling trailers/equipment.
• Light gauge tanks.
• Protection of high volume vacuum pumps and conveying systems.

Company Information

Large Nozzle Design Pressure Reducing Valve Threaded NPT / BSPT Bronze Material

Our Service

1.Swift delivery

For common parts, we can deliver the goods within 3 days

2.Original products

All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.

3.Quality Assurance

4.Technical Support

Including inspection,repair and maintenance, we can give all kinds of technical support.

5.Quickly responce

Our staffs will keep 24h online and answer your question very quickly.

A variety of controls for cryogenic systems including liquid and gas line-pressure buildup regulators, economizer (heat leak) back pressure valves, temperature safety valves, combination valves, shut-off valves and finalline/service-line regulators.
